TECH. DETAILS OF SMALL BIOGAS (METHANE / GOBAR GAS) ENGINES
AND POWER GENERATORS
SINGLE PHASE, 240 VOLTS, 50 Hz, A.C., SELF START WITHOUT BATTERY

Details/Model	HTBG-3500	HTBG-5000	HTBG-6500	HTBG-8000
Engine Type / C.I.Body	4 stroke	4 stroke	4 stroke	4 stroke
Engine Cooling Type	Air	Air	Air	Air
Cylinder	1	1	1	1
Bore x Stroke (mm)	76 x 76	85 x 80	85 x 110	95 x 110
Ignition System	Electronic	Electronic	Electronic	Electronic
Lub. Oil Sump Capacity	3 Litres	4 Litres	5 Litres	5 Litres
RPM	1500	1500	1500	1500
Biogas Consumption @ 100% load	1.25M3/Hr.	1.8M3/Hr.	2.4M3/Hr.	2.9M3/Hr.
Lub. Oil Consumption	10ml./Hr.	14ml./Hr.	18ml./Hr.	22ml./Hr.
Alternator Type/ Alu. Body	Slip ring	Slip ring	Slip ring	Slip ring
Rated Output (KW)	1.6	2.5	3.0	3.7
Current Ampere	5.8A	9.2A	11.6A	14.30A
D.C. Volt (Battery/Alternator)	12V	12V	12V	12V
Approx. Dimension (LxWxHt)	1300x800x850	1400x950x950	1400x950x950	1500x950x950
Approx. Dry Weight (Kgs)	200	240	290	320

(Water Cooled Engine is also available for above)

BIO-GAS (METHANE – GOBAR GAS) RUN POWER GENERATORS
THREE PHASE, 415 VOLTS, 50 Hz, 1500 RPM, O.8 P.F., AC,

Model	KVA	KW	AMP	Engiene HP	Engiene Cyl.	Engiene Make	Aspira.	Cooling
HTBG 5 W	5	4	7	9	1	HI-TECH	N.A	Air/Water
HTBG 75 W	7.5	6	10.4	11	1	HI-TECH	N.A	Air/Water
HTBG 10 W	10	8	14	15	2	HI-TECH	N.A	Air/Water
HTBG 15 W	15	12	21	21	2	HI-TECH	N.A	Water

NOTE : WE ARE USING 100 % ORIGINAL KIRLOSKAR PARTS IN THE ENGINE, FROM THE SUPPLIERS/MANUFACTURERS AND HENCE AS GOOD AS THE QUALITY OF KIRLOSKAR. WE ARE USING DOUBLE CAPACITY H.P. OF KVA, WITH GAC TYPE OUR MAKE MIXER, AIR + GAS BUTTERFLY VALVES CONNECTED WITH ENGINE’S GOVERNING SYSTEM, AND USING ELECTRONIC INGITION SYSTEM WITH INDIVIDUAL COIL FOR EACH CYLINDER.

NOTE : WE CAN ALSO MANUFACTURING PETROL OR PYROLYSIS OILRUN ENGINE AND WATER PUMPS OR POWER GENERATOR AS PER THE CUSTOMER’S REQUIREMENT.
